B And C DE400-8 B&c 1″ Exit Hf Compression Driver 8ohm N

Description

This item is brand-new, factory sealed.

DE400
* Current alternative DE400TN
* 100 W continuous program power capacity
* 1-in horn throat diameter
* 44 mm (1.7 in) aluminium voice coil
* Polyimide diaphragm
* 1200 – 18000 Hz response
* 108.5 dB sensitivity
* Compact Neodymium magnet assembly
* Throat diameter: 25 mm (1.0 in)
* Nominal impedance: 8 Ohms
* Minimum impedance: 7.7 Ohms
* Nominal power handling: 50 W
* Continuous power handling: 100 W
* Sensitivity (1W/1m): 108.5 dB
* Frequency range: 1 – 18 kHz
* Recommended crossover: 1.6 kHz
* Voice coil diameter: 44 mm (1.7 in)
* Winding material: Aluminium
* Inductance: 0.11 mH
* Diaphragm material: Polyimide
* Flux density: 1.8 T
* Magnet material: Neodymium Ring
* Mounting & Shipping Info
* Two M6 holes 180 Degrees on 76 mm (3 in) diameter
* Overall diameter: 85 mm (3.3 in)
* Depth: 44 mm (1.7 in)
* Net weight: 0.8 kg (1.8 lb)
* Shipping units: 8
* Shipping weight: 6.7 kg (14.7 lb)
* Shipping box: 220x220x150 mm (8.7×8.7×5.9 in)
* Replacement Diaphragm: MMD4008
