Description
This item is brand-new, factory sealed.
EDGE Hub
The Hub on Edge Gold 1000W & 1200W is now available separately
Connect to the motherboard using USB-USB and USB-Type A cables
4 ports in 2+2+2+1 format?500mA for each USB port
1 interface for speed feedback functionality
EDGE HUB
Elevate your power experience with the hub
AVAILABLE IN 2 COLORS
BLACK
WHITE
FAN PWM HUB
6 extended 4-pin fan connectors, each rated at 2A, to meet the demands of multi-fan setups.
1 interface for speed feedback functionality
USB HUB
4 ports support up to 7 downstream USB connections with a total 2.5A output, with Port 1 providing one USB signal and Ports 2, 3, and 4 each supporting two signals via 1-to-2 splitter cables, making it ideal for RGB controllers and other USB devices.
MODULAR USB & FAN PWM HUB
The external USB and fan PWM hub module offers versatile connectivity options. It can be attached directly to the PSU or connected via a PCIe power interface inside the case.
MOTHERBOARD SIGNAL CONNECTION
Offers two options for motherboard USB signal connection to accommodate different configurations.Model NAME
Edge HUBMODEL no
EG-HUB01WCOLOR
WhiteInput
Fan 12Vdc 12.5A
USB 5Vdc 2.5AFan Header Output
6 x header 12Vdc 2A for eachUSB Header Output
4 x header 5Vdc for each 500mA Total 2.5APower Source
Edge Gold PSU Connector PCIe 8-PINItem Dimension (L”xW”xH”)
7 x 4 x 2
Weight
1 lb
Warranty Information
2 years
